開發過程中會遇見很多app注冊時，需要通過手機發送驗證碼驗證 ，這是可以封裝一個驗證碼按鈕：
attrs.xml
|
1
2
3
4
5
6
7
8
9
10
11
12
13
|
<?xml version="1.0" encoding="utf-8"?><resources> <declare-styleable name="VerifyCodeButton"> <!--默認背景--> <attr name="android:background" /> <!--點擊后背景--> <attr name="clickedBackground" format="reference" /> <!--倒計時間--> <attr name="countdownTime" format="integer" /> <!--倒計時間后提示文字--> <attr name="countdownText" format="string" /> </declare-styleable></resources> |
自定義Button
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
|
public class VerifyCodeButton extends Button { private Context mContext; private int mClickedBackground;//點擊后背景 private int mBackground;//當前背景 private String mCountdownownText; private int mCountdownTime = 60; private TimeCount mTimeCount; public VerifyCodeButton(Context context) { this(context, null); } public VerifyCodeButton(Context context, AttributeSet attrs) { this(context, attrs, android.R.attr.buttonStyle); } public VerifyCodeButton(Context context, AttributeSet attrs, int defStyleAttr) { super(context, attrs, defStyleAttr); mContext = context; initAttrs(attrs); init(); } private void initAttrs(AttributeSet attrs) { TypedArray typedArray = mContext.obtainStyledAttributes(attrs, R.styleable.VerifyCodeButton); mBackground = typedArray.getResourceId(R.styleable.VerifyCodeButton_android_background, mBackground); mClickedBackground = typedArray.getResourceId(R.styleable.VerifyCodeButton_clickedBackground, mClickedBackground); mCountdownTime = typedArray.getInt(R.styleable.VerifyCodeButton_countdownTime, mCountdownTime); mCountdownownText = typedArray.getString(R.styleable.VerifyCodeButton_countdownText); typedArray.recycle(); } private void init() { setBackgroundResource(mBackground); mTimeCount = new TimeCount(mCountdownTime * 1000, 1000); } /** * 開始計時 */ public void start() { mTimeCount.start(); } /** * 取消計時 */ public void cancle() { mTimeCount.cancel(); setClickable(true); setText(mCountdownownText != null ? mCountdownownText : ""); setBackgroundResource(mBackground); } class TimeCount extends CountDownTimer { /** * @param millisInFuture 總時間 * @param countDownInterval 間隔時間 */ public TimeCount(long millisInFuture, long countDownInterval) { super(millisInFuture, countDownInterval); } /** * @param millisUntilFinished 當前時間 */ @Override public void onTick(long millisUntilFinished) { setClickable(false); setText(String.valueOf(millisUntilFinished / 1000 + "s")); setBackgroundResource(mClickedBackground); } @Override public void onFinish() { setClickable(true); setText(mCountdownownText != null ? mCountdownownText : ""); setBackgroundResource(mBackground); } }} |
自定義2個drawable
|
1
2
3
4
5
6
|
<?xml version="1.0" encoding="utf-8"?><shape xmlns:android="http://schemas.android.com/apk/res/android" android:shape="rectangle"> <corners android:radius="5dp" /> <solid android:color="#feacc3" /></shape> |
|
1
2
3
4
5
6
|
<?xml version="1.0" encoding="utf-8"?><shape xmlns:android="http://schemas.android.com/apk/res/android" android:shape="rectangle"> <corners android:radius="5dp" /> <solid android:color="#999999" /></shape> |
layout.xml
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
|
<?xml version="1.0" encoding="utf-8"?><LinearLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto" xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent" android:layout_height="match_parent" android:orientation="vertical" tools:context="com.sample.verify.MainActivity"> <com.sample.verify.widget.VerifyCodeButton android:id="@+id/btn_verify_code" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_gravity="center" android:layout_margin="10dp" android:background="@drawable/bg_btn_default" android:gravity="center" android:text="獲取驗證碼" android:textColor="#ffffff" android:textSize="14sp" app:clickedBackground="@drawable/bg_btn_clicked" app:countdownText="重新獲取" app:countdownTime="10" /> <Button android:id="@+id/btn_cancle" android:layout_width="wrap_content" android:layout_height="wrap_content" android:layout_gravity="center_horizontal" android:text="取消倒計時" /></LinearLayout> |
Activity
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
|
package com.sample.verify;import android.os.Bundle;import android.support.v7.app.AppCompatActivity;import android.view.View;import android.widget.Button;import com.sample.verify.widget.VerifyCodeButton;public class MainActivity extends AppCompatActivity implements View.OnClickListener { private VerifyCodeButton btn_verify_code; private Button btn_cancle; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_main); setTitle("驗證碼"); btn_verify_code = (VerifyCodeButton) findViewById(R.id.btn_verify_code); btn_cancle = (Button) findViewById(R.id.btn_cancle); btn_verify_code.setOnClickListener(this); btn_cancle.setOnClickListener(this); } @Override public void onClick(View v) { switch (v.getId()) { case R.id.btn_verify_code: btn_verify_code.start(); break; case R.id.btn_cancle: btn_verify_code.cancle(); break; } } @Override protected void onDestroy() { super.onDestroy(); if (btn_verify_code != null) { btn_verify_code.cancle(); } }} |
代碼下載：android實現驗證碼按鈕
以上就是本文的全部內容，希望對大家的學習有所幫助，也希望大家多多支持服務器之家。
