1.application.yml
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
|
server: port: 8184spring: application: name: rabbitmq-demo rabbitmq: host: 127.0.0.1 # ip地址 port: 5672 username: admin # 連接賬號 password: 123456 # 連接密碼 template: retry: enabled: true # 開啟失敗重試 initial-interval: 10000ms # 第一次重試的間隔時長 max-interval: 300000ms # 最長重試間隔，超過這個間隔將不再重試 multiplier: 2 # 下次重試間隔的倍數，此處是2即下次重試間隔是上次的2倍 exchange: topic.exchange # 缺省的交換機名稱，此處配置后，發送消息如果不指定交換機就會使用這個 publisher-confirm-type: correlated # 生產者確認機制，確保消息會正確發送，如果發送失敗會有錯誤回執，從而觸發重試 publisher-returns: true listener: type: simple simple: acknowledge-mode: manual prefetch: 1 # 限制每次發送一條數據。 concurrency: 3 # 同一個隊列啟動幾個消費者 max-concurrency: 3 # 啟動消費者最大數量 # 重試策略相關配置 retry: enabled: true # 是否支持重試 max-attempts: 5 stateless: false multiplier: 1.0 # 時間策略乘數因子 initial-interval: 1000ms max-interval: 10000ms default-requeue-rejected: true |
2.pom.xml引入依賴
|
1
2
3
4
5
|
<!-- rabbitmq --> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-amqp</artifactId> </dependency> |
3.常量類創建
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
|
/** * @author kkp * @ClassName RabbitMqConstants * @date 2021/11/3 14:16 * @Description */public class RabbitMqConstants { public final static String TEST1_QUEUE = "test1-queue"; public final static String TEST2_QUEUE = "test2-queue"; public final static String EXCHANGE_NAME = "test.topic.exchange"; /** * routingKey1 */ public final static String TOPIC_TEST1_ROUTINGKEY = "topic.test1.*"; public final static String TOPIC_TEST1_ROUTINGKEY_TEST = "topic.test1.test"; /** * routingKey1 */ public final static String TOPIC_TEST2_ROUTINGKEY = "topic.test2.*"; public final static String TOPIC_TEST2_ROUTINGKEY_TEST = "topic.test2.test";} |
4.配置Configuration
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
|
import com.example.demo.common.RabbitMqConstants;import lombok.extern.slf4j.Slf4j;import org.springframework.amqp.core.*;import org.springframework.amqp.rabbit.connection.CachingConnectionFactory;import org.springframework.amqp.rabbit.core.RabbitTemplate;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.beans.factory.annotation.Qualifier;import org.springframework.beans.factory.config.ConfigurableBeanFactory;import org.springframework.context.annotation.Bean;import org.springframework.context.annotation.Configuration;import org.springframework.context.annotation.Scope;/** * @author kkp * @ClassName RabbitMqConfig * @date 2021/11/3 14:16 * @Description */@Slf4j@Configurationpublic class RabbitMqConfig { @Autowired private CachingConnectionFactory connectionFactory; /** * 聲明交換機 */ @Bean(RabbitMqConstants.EXCHANGE_NAME) public Exchange exchange(){ //durable(true) 持久化，mq重啟之后交換機還在 // Topic模式 //return ExchangeBuilder.topicExchange(RabbitMqConstants.EXCHANGE_NAME).durable(true).build(); //發布訂閱模式 return ExchangeBuilder.fanoutExchange(RabbitMqConstants.EXCHANGE_NAME).durable(true).build(); } /** * 聲明隊列 * new Queue(QUEUE_EMAIL,true,false,false) * durable="true" 持久化 rabbitmq重啟的時候不需要創建新的隊列 * auto-delete 表示消息隊列沒有在使用時將被自動刪除 默認是false * exclusive 表示該消息隊列是否只在當前connection生效,默認是false */ @Bean(RabbitMqConstants.TEST1_QUEUE) public Queue esQueue() { return new Queue(RabbitMqConstants.TEST1_QUEUE); } /** * 聲明隊列 */ @Bean(RabbitMqConstants.TEST2_QUEUE) public Queue gitalkQueue() { return new Queue(RabbitMqConstants.TEST2_QUEUE); } /** * TEST1_QUEUE隊列綁定交換機，指定routingKey */ @Bean public Binding bindingEs(@Qualifier(RabbitMqConstants.TEST1_QUEUE) Queue queue, @Qualifier(RabbitMqConstants.EXCHANGE_NAME) Exchange exchange) { return BindingBuilder.bind(queue).to(exchange).with(RabbitMqConstants.TOPIC_TEST1_ROUTINGKEY).noargs(); } /** * TEST2_QUEUE隊列綁定交換機，指定routingKey */ @Bean public Binding bindingGitalk(@Qualifier(RabbitMqConstants.TEST2_QUEUE) Queue queue, @Qualifier(RabbitMqConstants.EXCHANGE_NAME) Exchange exchange) { return BindingBuilder.bind(queue).to(exchange).with(RabbitMqConstants.TOPIC_TEST2_ROUTINGKEY).noargs(); } /** * 如果需要在生產者需要消息發送后的回調， * 需要對rabbitTemplate設置ConfirmCallback對象， * 由于不同的生產者需要對應不同的ConfirmCallback， * 如果rabbitTemplate設置為單例bean， * 則所有的rabbitTemplate實際的ConfirmCallback為最后一次申明的ConfirmCallback。 * @return */ @Bean @Scope(ConfigurableBeanFactory.SCOPE_PROTOTYPE) public RabbitTemplate rabbitTemplate() { RabbitTemplate template = new RabbitTemplate(connectionFactory); return template; }} |
5.Rabbit工具類創建
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
|
import lombok.extern.slf4j.Slf4j;import org.springframework.amqp.core.Message;import org.springframework.amqp.rabbit.connection.CorrelationData;import org.springframework.amqp.rabbit.core.RabbitTemplate;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.stereotype.Component;import java.util.UUID;/** * @author kkp * @ClassName RabbitMqUtils * @date 2021/11/3 14:21 * @Description */@Slf4j@Componentpublic class RabbitMqUtils implements RabbitTemplate.ConfirmCallback, RabbitTemplate.ReturnCallback{ private RabbitTemplate rabbitTemplate; /** * 構造方法注入 */ @Autowired public RabbitMqUtils(RabbitTemplate rabbitTemplate) { this.rabbitTemplate = rabbitTemplate; //這是是設置回調能收到發送到響應 rabbitTemplate.setConfirmCallback(this); //如果設置備份隊列則不起作用 rabbitTemplate.setMandatory(true); rabbitTemplate.setReturnCallback(this); } /** * 回調確認 */ @Override public void confirm(CorrelationData correlationData, boolean ack, String cause) { if(ack){ log.info("消息發送成功：correlationData({}),ack({}),cause({})",correlationData,ack,cause); }else{ log.info("消息發送失敗：correlationData({}),ack({}),cause({})",correlationData,ack,cause); } } /** * 消息發送到轉換器的時候沒有對列,配置了備份對列該回調則不生效 * @param message * @param replyCode * @param replyText * @param exchange * @param routingKey */ @Override public void returnedMessage(Message message, int replyCode, String replyText, String exchange, String routingKey) { log.info("消息丟失：exchange({}),route({}),replyCode({}),replyText({}),message:{}",exchange,routingKey,replyCode,replyText,message); } /** * 發送到指定Queue * @param queueName * @param obj */ public void send(String queueName, Object obj){ CorrelationData correlationId = new CorrelationData(UUID.randomUUID().toString()); this.rabbitTemplate.convertAndSend(queueName, obj, correlationId); } /** * 1、交換機名稱 * 2、routingKey * 3、消息內容 */ public void sendByRoutingKey(String exChange, String routingKey, Object obj){ CorrelationData correlationId = new CorrelationData(UUID.randomUUID().toString()); this.rabbitTemplate.convertAndSend(exChange, routingKey, obj, correlationId); }} |
6.service創建
|
1
2
3
4
5
6
|
public interface TestService { String sendTest1(String content); String sendTest2(String content);} |
7.impl實現
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
|
import com.example.demo.common.RabbitMqConstants;import com.example.demo.util.RabbitMqUtils;import lombok.extern.slf4j.Slf4j;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.stereotype.Service;/** * @author kkp * @ClassName TestServiceImpl * @date 2021/11/3 14:24 * @Description */@Service@Slf4jpublic class TestServiceImpl implements TestService { @Autowired private RabbitMqUtils rabbitMqUtils; @Override public String sendTest1(String content) { rabbitMqUtils.sendByRoutingKey(RabbitMqConstants.EXCHANGE_NAME, RabbitMqConstants.TOPIC_TEST1_ROUTINGKEY_TEST, content); log.info(RabbitMqConstants.TOPIC_TEST1_ROUTINGKEY_TEST+"***************發送成功*****************"); return "發送成功！"; } @Override public String sendTest2(String content) { rabbitMqUtils.sendByRoutingKey(RabbitMqConstants.EXCHANGE_NAME, RabbitMqConstants.TOPIC_TEST2_ROUTINGKEY_TEST, content); log.info(RabbitMqConstants.TOPIC_TEST2_ROUTINGKEY_TEST+"***************發送成功*****************"); return "發送成功！"; }} |
8.監聽類
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
|
import com.example.demo.common.RabbitMqConstants;import lombok.extern.slf4j.Slf4j;import org.springframework.amqp.core.ExchangeTypes;import org.springframework.amqp.core.Message;import org.springframework.amqp.rabbit.annotation.Exchange;import org.springframework.amqp.rabbit.annotation.Queue;import org.springframework.amqp.rabbit.annotation.QueueBinding;import org.springframework.amqp.rabbit.annotation.RabbitListener;import org.springframework.stereotype.Component;import com.rabbitmq.client.Channel;/** * @author kkp * @ClassName RabbitMqListener * @date 2021/11/3 14:22 * @Description */@Slf4j@Componentpublic class RabbitMqListener { @RabbitListener(queues = RabbitMqConstants.TEST1_QUEUE) public void test1Consumer(Message message, Channel channel) { try { //手動確認消息已經被消費 channel.basicAck(message.getMessageProperties().getDeliveryTag(), false); log.info("Counsoum1消費消息：" + message.toString() + "。成功！"); } catch (Exception e) { e.printStackTrace(); log.info("Counsoum1消費消息：" + message.toString() + "。失敗！"); } } @RabbitListener(queues = RabbitMqConstants.TEST2_QUEUE) public void test2Consumer(Message message, Channel channel) { try { //手動確認消息已經被消費 channel.basicAck(message.getMessageProperties().getDeliveryTag(), false); log.info("Counsoum2消費消息：" + message.toString() + "。成功！"); } catch (Exception e) { e.printStackTrace(); log.info("Counsoum2消費消息：" + message.toString() + "。失敗！"); } }} |
9.Controller測試
|
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
|
import com.example.demo.server.TestService;import jdk.nashorn.internal.objects.annotations.Getter;import lombok.extern.slf4j.Slf4j;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.web.bind.annotation.*;import java.util.Map;/** * @author kkp * @ClassName TestController * @date 2021/11/3 14:25 * @Description */@Slf4j@RestController@RequestMapping("/enterprise")public class TestController { @Autowired private TestService testService; @GetMapping("/finance") public String hello3(@RequestParam(required = false) Map<String, Object> params) { return testService.sendTest2(params.get("entId").toString()); } /** * 發送消息test2 * @param content * @return */ @PostMapping(value = "/finance2") public String sendTest2(@RequestBody String content) { return testService.sendTest2(content); }} |
到此這篇關于springboot2.5.6集成RabbitMq實現Topic主題模式的文章就介紹到這了,更多相關springboot集成RabbitMq內容請搜索服務器之家以前的文章或繼續瀏覽下面的相關文章希望大家以后多多支持服務器之家！
